DAY LIGHT

BACK

DAY LIGHT

Pin Type / Screw Type

Download PDF
Product details
Wattage 3.5W
5W
7W
9W
12W
Cap Type B22/ E27
B22/ E27
B22/ E27
B22/ E27
B22/ E27
Rated Current (mA) 29 23 33
41
53
Rated Lumen Output (lm) 315 450
630
810
1080
Efficacy (lm/W) 90
90
90
90
90
Equal wattage of GLS lamp 25W
40W
60W
75W
100W


General Data
Standard Compliance SLS 1458 and SLS 1530
Warranty 24 Months
Technical Data
Rated Voltage (V) 220-240V AC
Rated Frequency (Hz) 50
Energy Saving
87%
Colour Temperature (K)
6500 - Daylight
Life Span (Hrs)
25000
Features
Durable
Lower energy consumption
RoHS Compliant
Very low heat emission
High lumen output
Surge supression resistor (Varistor)
Can operate on a wide voltage range of 160V AC - 265V AC
Features for Protection;
Heat sink available
Noise filter available
Having resettable resister
Instructions
Use only for indoor applications
Do not use this LED with dimming circuits / switches
Do not use in air tight luminaires or enclosed fittings
Do not use in ambient temperatures below 0°C and above 45°C or in
damp or moist areas
