Standards and Country of Origin | |
Certification Mark | SLS 734
|
Country of manufacture | Sri Lanka
|
Warranty | Lifetime
|
Technical data | |
Key Features
|
Embossed terminal markings on the rear housing ensure terminal identification & saves wiring time
|
Internal contact points covered with silver coating enhances the electric strength of the switch
|
|
3-Pin operated safety shutter ensures earth terminal makes contact first and breaks last, thereby providing maximum safety
|
|
The front plate made from polycarbonate is of high impact strength and has fire retardant properties
|
Power Supply | |
Rated Voltage | 250V AC
|
Rated Current | 13A
|
Dimensions | |
Plate Size (H*W) | 86mm x 86mm
|
Terminal Space Capacities | L/N Terminal - 2 x 2.5mm2, E Terminal - 2 x 2.5mm2
|
Depth | 20mm
|
Mounting Centers | 60.3mm
|
Compatible Sunk Box | Standard Sunk Box (Depth - 35mm)
|
Performance Parameters | |
Electrical Endurance | 15000 cycles (30000 Movements)
|
Material Overview | |
Plastic | Polycarbonate and Nylon-FR grade
|
Metal | Brass, Phosphor Bronze, Silver on the contact points
|
